  • Page 1 Temposonics ® Magnetostrictive Linear Position Sensors ET SSI ATEX / IECEx / CEC / NEC Certified Operation Manual...

  • Page 2: Table Of Contents

    Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual Table of contents 1. Introduction ...............................3 1.1 Purpose and use of this manual ..................................3 1.2 Used symbols and warnings ..................................3 2. Safety instructions ...............................3 2.1 Intended use ........................................

  • Page 3: Introduction

    1 to item 4 and only in conjunction with the third-party devices and Error in position measurement are installed in a wrong order components recommended or approved by MTS Sensors. As a prereq- Wrong connection Signal output is disturbed uisite of proper and safe operation, the product requires correct trans-...

  • Page 4: Installation, Commissioning And Operation

    (VDE 0100, part 540; IEC 364-5-54). (ESD). 5. Sensors from MTS Sensors are approved only for the intended 11. Before applying power, ensure that nobody’s safety is jeopar- use in industrial environments (see chapter “2.1 Intended use”...

  • Page 5: Safety Instructions For Use In Explosion-Hazardous Areas

    For diagnostic purposes, the sensor can be returned to MTS Sensors. Any shipment cost is the responsibility of the sender . For a corre- sponding form, see chapter “9. Appendix” on page 21. 2/ See also applicable MTS Sensors terms of sales and delivery on www.mtssensors.com...

  • Page 6: Identification

    Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual 3. Identification 3.1 Order code Temposonics ® a Sensor model e Operating voltage T Rod +24 VDC (−15 / +20 %) Version (see “Certification of Temposonics ET (version A and b Design ®...

  • Page 7: Nameplate (Example)

    Principle of operation and system construction The absolute, linear position sensors provided by MTS Sensors Modular mechanical and electronic construction rely on the company’s proprietary Temposonics magnetostrictive •...

  • Page 8: Styles And Installation Of Temposonics ® Et

    Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual 4.2 Styles and installation of Temposonics ® ET-F / -M / -S / -W, example: Version A / N Sensor electronics housing Null zone Stroke length Dead zone 50…3000 63.5...
  • Page 9 Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual Hydraulics sealing There are two ways to seal the flange contact surface (Fig. 7): 1. A sealing by using an O-ring (e.g. 22.4 × 2.65 mm (0.88 × 0.1 in.), 25.07 ×...

  • Page 10: Magnet Installation

    Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual 4.3 Magnet installation Magnet mounting with magnetic material When using magnetic material the dimensions of Fig. 11 must Typical use of magnets be observed. A. If the position magnet aligns with the drilled piston rod Magnet Benefits B.

  • Page 11: Electrical Connection

    Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual Start and end positions of the position magnets Grounding of rod sensors Consider the start and end positions of the position magnets during Connect the sensor electronics housing to machine ground. Ground the installation.

  • Page 12: Frequently Ordered Accessories

    Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual 4.5 Frequently ordered accessories – Additional options available in our Accessories Guide 551 444 Position magnets Ø 32.8 (Ø 1.29) Ø 4.3 Ø 32.8 Ø 25.4 (Ø...
  • Page 13 Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual Optional installation hardware Cable 60 (2.36) 16 (0.63) ¾"-16 UNF-3A M18×1.5-6g (0.34) (0.43) Ø 3.2 (Ø 0.13) M3 fastening screws (6×) 3.2 (0.13) Fixing clip for rod with Ø 10 mm Hex jam nut M18×1.5-6g Hex jam nut ¾"-16 UNF-3A Tefl...

  • Page 14: Operation

    5. Check the pre-set span start and end values of the measuring range (Fig. 13) and correct them via the customer’s control system if necessary, or via the MTS Sensors service tool. Fig. 19: Timing diagram The operation of the service tool is described in detail on the Dependent on the baud rate chosen in the controller the following following pages.
  • Page 15 – without Never connect / disconnect the sensor when voltage is applied. opening the sensor. For this, the following MTS Sensors programming tool is available (see page 12). Step 1: Connect PC programmer...
  • Page 16 Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual MTS ET SSI software user interface Device Settings The following parameters can be modified: SSI Settings (Fig. 24) Format: Binary / Gray Data Length: 24 bits / 25 bits Resolution: 5 µm / 10 µm / 20 µm / 50 µm / 100 µm Mode:...
  • Page 17 Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual Measurement After clicking the Start Read button the current position of the magnet is shown. Click the Stop Read button to stop the measurement (Fig. 26). The View button provides a graphic display of the magnet’s position (Fig.

  • Page 18: Maintenance And Troubleshooting

    0…16777215 6.3 Repair (see Fig. 25) Wrong quantity of magnets Default error value: 0 Repairs on the sensor may be performed only by MTS Sensors or an Adapted error value: explicitly authorized body. 0…16777215 (see Fig. 25) 6.4 List of spare parts 6.2 Maintenance...

  • Page 19: Technical Data Of Temposonics ® Et

    Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual 8. Technical data of Temposonics ® Output Interface SSI (Synchronous Serial Interface) – Differential signal in SSI standard Data format Binary, gray Data length 24 bit / 25 bit Measured value Position Measurement parameters...
  • Page 20 Temposonics ET SSI ATEX / IECEx / CEC / NEC Certified ® Operation Manual Certifi cation II 3G Ex nC IIC T4 Gc II 3D Ex tc IIIC T130 °C Dc IP66 / IP68 Class I/II/III Div 2 T4 ABCDFG Class I Zone 2 T4 IIC Zone 22 AEx tc T4 IIIC Dc −40 °C ≤...

  • Page 21: Appendix

    Do not specify chemical formulas. In the event of suspected penetration of substances into the sensor, Please include safety data sheets of the substances, if applicable. consult MTS Sensors to determine measures to be taken before shipment. Short description of malfunction:...

  • Page 22: Declaration Of Conformity

    10. Declaration of conformity EC15.012A EU Declaration of Conformity EU-Konformitätserklärung Déclaration UE de Conformité MTS Systems Corporation - Sensors Division, 3001 Sheldon Drive, 27513 Cary, NC, USA MTS Sensor Technologie GmbH & Co. KG, Auf dem Schueffel 9, 58513 Luedenscheid, Germany declares as manufacturer in sole responsibility that the position sensor type erklärt als Hersteller in alleiniger Verantwortung, dass der Positionssensor Typ déclare en qualité...
  • Page 23 EU Declaration of Conformity EC17.004A EU-Konformitätserklärung Déclaration UE de Conformité MTS Sensor Technologie GmbH & Co. KG, Auf dem Schueffel 9, 58513 Luedenscheid, Germany declares as manufacturer in sole responsibility that the position sensor type erklärt als Hersteller in alleiniger Verantwortung, dass der Positionssensor Typ déclare en qualité...
  • Page 24 QPS Evaluation Services Inc Testing, Certification and Field Evaluation Body Accredited in Canada, the USA, and Internationally File LR1346 CERTIFICATE OF COMPLIANCE (ISO TYPE 3 CERTIFICATION SYSTEM) Issued to MTS Sensor Technologie GmbH & Co KG Address Auf Dem Schüffel 9, Lüdenscheid, Germany, D-58513 Project Number LR1346-3...
  • Page 25 QPS Evaluation Services Inc Testing, Certification and Field Evaluation Body Accredited in Canada, the USA, and Internationally File LR1346 Annex: Product: Linear Position Sensors Tempsonics ® E-Series ET Models: SSI Output, Analog & Digital Start/Stop Model (output) Canada Analog Ex nC IIC T4 Gc Class I/II/III Div 2 T4 ABCDFG Ex tc IIIC T130°C Dc IP66/68 Class I Zone 2 T4 IIC...
  • Page 27 MTS, Temposonics and Level Plus are registered trademarks of MTS Systems Corporation in the United States; MTS SENSORS and the MTS SENSORS logo are trademarks of MTS Systems Corporation within the United States. These trademarks may be protected in other countries. All other trademarks are the property of their respective owners. Copyright © 2018 MTS Systems Corporation. No license of any intellectual property rights is granted.
