Threaded flange »C« & »D« (for bottom or side entry)
PUR-cable:
Ø 6 (Ø 0.24)
Bend radius:
> 24 (> 0.94)
Length for bottom cable entry:
65 / 170 / 230 / 350
(2.6 / 6.7 / 9.1 / 13.8)
Length for side cable entry:
250 / 400 / 600
(9.8 / 15.7 / 23.6)
Cable for bottom
Threaded flange »G« (for bottom or side entry)
PUR-cable:
Ø 6 (Ø 0.24)
Bend radius:
> 24 (> 0.94)
Length for bottom cable entry:
65 / 170 / 230 / 350
(2.6 / 6.7 / 9.1 / 13.8)
Length for side cable entry:
250 / 400 / 600
(9.8 / 15.7 / 23.6)
Threaded flange »M« & »T« (for bottom or side entry)
PUR-cable:
Ø 6 (Ø 0.24)
Bend radius:
> 24 (> 0.94)
Length for bottom cable entry:
65 / 170 / 230 / 350
(2.6 / 6.7 / 9.1 / 13.8)
Length for side cable entry:
250 / 400 / 600
Cable for bottom
(9.8 / 15.7 / 23.6)
Pressure fit flange »S« (for bottom or side entry)
PUR-cable:
Ø 6 (Ø 0.24)
Bend radius:
> 24 (> 0.94)
Length for bottom cable entry:
65 / 170 / 230 / 350
(2.6 / 6.7 / 9.1 / 13.8)
Length for side cable entry:
250 / 400 / 600
Cable for bottom
(9.8 / 15.7 / 23.6)
Controlling design dimensions are in millimeters and measurements in ( ) are in inches
Fig. 13: Temposonics RD4 flanges with ring manget
26.9
(1.1)
Cable for side
cable entry cable entry
26.9
(1.1)
Cable for bottom Cable for side
cable entry cable entry
26.9
(1.1)
Cable for side
cable entry cable entry
26.9 f6
(1.1)
Cable for side
cable entry cable entry
Null zone
32
51
(1.36) (2.01)
A/F 46
Flange »C«: M18×1.5-6g
4.5
(0.18) Flange »D«: ¾"-16 UNF-3A
Null zone Stroke length
32 51
(1.36) (2.01)
A/F 24
4.5 25 Flange »G«: M18×1.5-6g
(0.18) (1)
Null zone
32 51
(1.36) (2.01)
A/F 23
4.5 25 Flange »M«: M18×1.5-6g
Flange »T«: ¾"-16 UNF-3A
(0.18) (1)
Null zone Stroke length
32
21.4 25...2540
(1.36) (0.84) (1...100)
4.5 12.7
(0.18) (0.5)
I 15 I
Temposonics R-Series Powerlink V2
®
Stroke length Dead zone
25...5080 63.5 / 66*
(1...200) (2.5 / 2.6)
* > 5000 mm (196.85 in.) stroke length
Dead zone
25...5080 63.5 / 66*
(1...200) (2.5 / 2.6*)
* > 5000 mm (196.85 in.) stroke length
Stroke length Dead zone
25...5080 63.5 / 66*
(1...200) (2.5 / 2.6)
* > 5000 mm (196.85 in.) stroke length
Dead zone
63.5
(2.5)
