3700 Series Flat Panel Industrial PC

Unpacking the System

When you remove the system from its shipping container, verify that you have the
parts listed below. Save the box and inner wrapping in the event you need to reship
the unit.
3700 series computer
• • • •
Documentation kit, which includes:
• • • •
•
•
•
•
•

Quick Startup

This section gives you the steps to get the system up and running without
explaining the capabilities and options.
Remove power from the unit and disconnect the power cord before making any
adjustments to the inside or outside of the computer.
For Hazardous Locations installation, review "Hazardous Locations Installation"
in Chapter 2 before startup.
To prepare the system for use, perform the following steps.
1. Attach optional keyboard to the keyboard port.
2. Attach optional mouse to the mouse port.
3. Attach other optional equipment following the instructions in Chapter 2.
4. Attach the power cord from the power receptacle to a properly grounded 115/230
VAC, 50-60 Hz outlet. (See Chapter 2, AC Power Cable.)
5. Turn on power to the unit (via an outlet power switch if applicable). The system
will boot up into the operating system.
6. Install application software via the floppy, the CD-ROM, or the network, as
applicable.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Power connector
10-32 hex nuts (for panel mounting with the studs)
Cable clamp and screw (for strain relief of power cord)
Documentation and Support Library CD-ROM
Operating System Recovery Media or operating system installation
disk (CD-ROM)
Warning
Warning
11
Chapter 1 – Introduction
143311 (H)
