4117T Light Duty Industrial PC

Unpacking the System

When you remove the system from its shipping container, verify that you have the
parts listed below. Save the box and inner wrapping in the event you need to reship
the unit.
4117T Unit
• • • •
Documentation kit, which includes:
• • • •

Quick Startup

This section gives you the steps to get the system up and running without explaining
the capabilities and options.
Remove power from the unit and disconnect the power cord before making any
adjustments to the inside or outside of the computer.
To prepare the system for use, perform the following steps.
1. Attach optional keyboard to the keyboard port, and optional mouse to the mouse
port.
2. Confirm that the 100-240 VAC selector switch on the power supply is set
appropriately.
3. Attach the power cord from the power receptacle to a properly grounded 100-
240 VAC, 50-60 Hz outlet.
4. Turn on power to the unit (via an outlet power switch if applicable). The system
will boot up into the operating system.
5. Install application software via the CD-ROM, or the network.
Power cable
Twelve panel mounting clamps
Documentation and Support Library CD-ROM
Operating System Recovery Media or retail operating system (CD-
ROM)
Warning
