Xycom 3700 Series User Manual page 50

3700 Series Flat Panel Industrial PC
3712KPM(T) F/A Key LED Off (Function Mode)
3715KPM(T)
Description Keyboard
of Key Equivalent
PF11 / ( F31
PF12 / ) F32
PF13 / ? F33
PF14 / ^ F34
PF15 / % F35
PF16 / $ F36
PF17 / @ F37
PF18 / < F38
PF19 / > F39
PF20 / ~ F40
1
CTRL CTRL
1
SHIFT SHIFT
ESC ESC
1
ALT ALT
TAB TAB
DEL DEL
F/A
SPACE SPACE
BACKSPACE BACKSPACE
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
. .
0 0
= =
PgUp PgUp
up arr up arr
2
+ +
left arr left arr
HOME HOME
right arr right arr
PgDn PgDn
down arr down arr
2
- -
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 3-6. Default Keypad Keycodes
Make Break Codes
Codes
11 05 F0 05 F0 11
11 06 F0 06 F0 11
11 04 F0 04 F0 11
11 0C F0 0C F0 11
11 03 F0 03 F0 11
11 0B F0 0B F0 11
11 83 F0 83 F0 11
11 0A F0 0A F0 11
11 01 F0 01 F0 11
11 09 F0 09 F0 11
14 F0 14
12 F0 12
76 F0 76
11 F0 11
0D F0 0D
E0 12 E0 71 E0 F0 71 E0 F0 12
29 F0 29
66 F0 66
16 F0 16
1E F0 1E
26 F0 26
25 F0 25
2E F0 2E
36 F0 36
3D F0 3D
3E F0 3E
46 F0 46
49 F0 49
45 F0 45
55 F0 55
E0 12 E0 7D E0 F0 7D E0 F0 12
E0 12 E0 75 E0 F0 75 E0 F0 12
79 F0 79
E0 12 E0 6B E0 F0 6B E0 F0 12
E0 12 E0 6C E0 F0 6C E0 F0 12
E0 12 E0 74 E0 F0 74 E0 F0 12
E0 12 E0 7A E0 F0 7A E0 F0 12
E0 12 E0 72 E0 F0 72 E0 F0 12
7B F0 7B
44
Chapter 3 – Keypad Utility Program
F/A Key LED On (Alpha Mode)
Keyboard Make
Equivalent Codes
( 12 46
) 12 45
? 12 4A
^ 12 36
% 12 2E
$ 12 25
@ 12 1E
< 12 41
> 12 49
~ 12 0E
CTRL 14
SHIFT 12
ESC 76
ALT 11
TAB 0D
DEL E0 12 E0 71
SPACE 29
BACKSPACE 66
1 16
2 1E
3 26
4 25
5 2E
6 36
7 3D
8 3E
9 46
. 49
0 45
= 55
PgUp E0 12 E0 7D
up arr E0 12 E0 75
+ 79
left arr E0 12 E0 6B
HOME E0 12 E0 6C
right arr E0 12 E0 74
PgDn E0 12 E0 7A
down arr E0 12 E0 72
- 7B
Break Codes
F0 12 F0 46
F0 12 F0 45
F0 12 F0 4A
F0 12 F0 36
F0 12 F0 2E
F0 12 F0 25
F0 12 F0 1E
F0 12 F0 41
F0 12 F0 49
F0 12 F0 0E
F0 14
F0 12
F0 76
F0 11
F0 0D
E0 F0 71 E0 F0 12
F0 29
F0 66
F0 16
F0 1E
F0 26
F0 25
F0 2E
F0 36
F0 3D
F0 3E
F0 46
F0 49
F0 45
F0 55
E0 F0 7D E0 F0 12
E0 F0 75 E0 F0 12
F0 79
E0 F0 6B E0 F0 12
E0 F0 6C E0 F0 12
E0 F0 74 E0 F0 12
E0 F0 7A E0 F0 12
E0 F0 72 E0 F0 12
F0 7B
143311 (H)
