Appendix A – Technical Specifications

Hardware Specifications

Table A - 1 lists the hardware specifications for the 3712KPM(T), 3715T and
3715KPM(T).
Characteristic
Mechanical
Height
Front Panel
Width
Front Panel
Depth
overall
behind front panel
front panel protrusion 1.00 in (25.4 mm)
29 lb (13.15 kg)
Weight
Electrical
AC 100-240 V AC, 50-60 Hz (auto ranging), 5.0 A maximum
DC
19-36 VDC, 4.8 A @ 19 VDC typical (20 A maximum)
Caution: 4.4A typical @19 VDC does not include power for the expansion slots.
Power Supply
AC 200 watts
DC 300 watts
Four available expansion slots:
one ½ length PCI
Passive
one full length PCI
Backplane
one full length ISA
one full length PCI or ISA
+3.3V
+5V
Power available –5V
for expansion in +12V
AC units –12V
Caution: +5V and +3.3V combined cannot to exceed 36 watts
+3.3 V
+5 V
Power available
–5 V
for expansion in
+12 V
DC units
–12 V
Caution: –5V and –12V combined cannot exceed 0.8 amps.
Mounting Mount in panel or in 19 in rack
Flat Panel 12.1" TFT color display
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table A - 1. Hardware Specifications
Hardware Specification
3712KPM(T)
12.22 in (310.38 mm)
19.00 in (482.6 mm)
7.40 in (187.96 mm)
6.40 in (162.56 mm)
10A maximum
6A maximum
0.2A maximum
4.9A maximum
0.5A maximum
-5V and –12V combined cannot exceed 8 watts
9 maximum
7A maximum
0.54A maximum
8A maximum
0.7A maximum .
62
3715T & 3715KPM(T)
Front Panel 13.97 in (354.84 mm)
Front Panel 19.00 in (482.6 mm)
overall 7.64 in (194.06 mm)
behind front panel 6.64 in (168.66 mm)
front panel protrusion 1.00 in (25.4 mm)
37 lb (16.78 kg)
15" TFT color display
143311 (H)
