Chapter 1 – Introduction

Product Overview

The 3700 series of Flat Panel Industrial Computers combines an Intel
®
Pentium
package for the factory floor and other harsh environments. The PC features an
open architecture to meet a wide variety of applications that require both a
powerful PC and a durable industrial enclosure. The system integrates a computer
card cage, mass storage, display, and power supply in a reliable industrial form
factor.
The 3715T is an industrial PC with touch screen display. The 3712KPM and
3715KPM are industrial PCs, which contain a display, an integrated keypad and an
integrated mouse. The 3712KPMT and 3715KPMT are industrial PCs, which
contain an integrated keypad, an integrated mouse, and a touch screen display.
The front panels of the 3700 units are sealed to NEMA TYPE 4/4X/12 (UL 50)
and IP65 (IEC 60529) standards and are protected by an impact-resistant shield.
The processor board combines all the functions of a complete PC/AT compatible
computer on a single industrially-hardened circuit board. Refer to the AIM3 CPU
manual for more information on processor and hardware features.
The system's modular design allows easy access to expansion boards, switches,
power supply, flat-panel display, and disk drives.

Standard Features

The 3700 unit comes standard with the following:
AIM3 CPU Board
• • • •
•
•
•
•
•
•
•
•
•
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
III processor with a flat-panel display to offer a powerful, compact
Two serial COM ports, with one configured as RS-232 and one
configurable as either RS-232 or RS-485
Parallel port
VGA port
®
Intel Socket 370 Celeron
AGP video controller, 4 MB system video RAM, up to 32 MB
available
PCI local-bus IDE controller
Two 168-pin SDRAM DIMM sites that support 128, & 256 MB
DIMMs, for up to 512 MB total memory
Two USB 1.1 ports
100MHz or 133MHz front side bus depending on the Celeron or
Pentium III processor type
1
® ®
or Pentium III options up to 1.26GHz
® ®
Celeron or
