Power Panel - Xycom 3700 Series User Manual

3700 Series Flat Panel Industrial PC

Power Panel

Figure 1-5 shows the 3700 System power panel, and Table 1-4 outlines the
features of the power panel.
Power connector
Figure 1-5. 3700 Side Panel with Fan Filter and Power Connector
Feature
Power Connector
Fan and Filter
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 1-4. 3700 Power Panel Features
Description
This is a 3-pin connector. Refer to the special Hazardous Locations
Installation instructions in Chapter 2.
The filter can be replaced or removed for cleaning. See Chapter 4
for details on the fan filter assembly.
10
Chapter 1 – Introduction
Fan and filter
143311 (H)
