3700 Series Flat Panel Industrial PC
This procedure assumes that the computer hard disk drive has been
completely corrupted or replaced.
This procedure will destroy data that may exist on the hard disk drive.

Installing Drivers

This section describes how to install the video drivers, the video expansion
capability, and the touch screen drivers associated with the 3700 series.

Video Drivers

Video drivers and the related expansion utilities are on the Documentation and
Support Library CD that is included with the documentation kit.
For the AIM3 system, choose the video driver for your operating system from the
following directory on the Documentation and Support Library CD:
\DRIVERS\VIDEO\AIM3 142338

Video Expansion

This section deals with the hardware expansion capability of the video controller
chip in DOS applications.
It is not necessary to read this section if you are a Windows® or OS/2 user and
do not plan to run DOS applications.
Unlike a CRT monitor, a flat panel display has a fixed horizontal and vertical
resolution. There are many DOS video modes whose resolution is less than that of
a flat panel display. To more efficiently make use of the flat panel display's active
area, it is necessary to employ an expansion technique that stretches the lower
resolution information to fill the higher resolution of the display.
For example, DOS defaults to VGA video mode 3+. This is an 80-column, 25-row
text-only screen whose effective resolution is 640 dots x 400 scan lines. Therefore,
the 800 x 600 system display will be only partially filled by the 640 x 400
resolution of this particular mode. The expansion function uses lower resolutions
that will better utilize the display by stretching the information in an attempt to fill
the display.
Operating systems such as Microsoft Windows® 98 and Windows® NT use
display drivers to handle the different flat panel displays. In those cases, expansion
is not necessary since there is a specific driver for each resolution display.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Note
Warning
Note
60
Chapter 5 – Troubleshooting
143311 (H)
