Dual Usb Connector (Usb1); Parallel Port Connector (Lpt1) - Xycom 3700 Series User Manual

3700 Series Flat Panel Industrial PC

Dual USB Connector (USB1)

The following table lists the signal definitions for the two USB connectors.
Pin
1A
2A
3A
4A

Parallel Port Connector (LPT1)

The following table shows the signal definitions for the DB-25 LPT1 connector.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
