3700 Series Flat Panel Industrial PC

Exit

Files
<Company Name> KP3 Utility: MAIN
Figure 3-1. Main Menu, showing first-level pull-down menus
Exit
Exit closes any open files and exits the utility.
purpose.

Files Menu

When you choose Files, a pull-down menu will display the following choices:
Open, Close, Save, Save As, Delete, and Exit. The following table describes these
menu commands.
Command
Open
Close
Save
Save As
Delete
Exit
You can save files containing keypad macro sets (a macro for each key) on disk,
and then load them into memory to view, edit, teach, or download to the keyboard
controller. Some of these files may be included in the utility package for use in
reconfiguring the keypads for different software packages, and as templates for
defining completely new keypad macro sets.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Macros
Open Function Keys
Alpha Keys
Close
Save
Save As
Delete
Exit
works for exiting the other menus as well.
ESC
Table 3-1. Files Menu
Description
Opens a file that contains a macro set for the keypad and loads the
contents into memory. Any macro set in memory is overwritten. Once
loaded, the macro set is available to edit, view, teach, or download to
the keyboard controller.
Clears the macro set from memory and closes the file from which the
set came.
Copies the macro set from memory back into its original file. The
original file contents are overwritten.
Creates a new file under the specified name and copies the macro set
from memory into it. For example, to define different sets of codes,
save each set under a different name and download the one you wish
to use.
Deletes a file.
Returns to the Main Menu.
38
Chapter 3 – Keypad Utility Program
Upload Download
.
KP Ctl Version
Exit
L-Arrow, R-Arrow, Enter
can also be used for this
ESC
Utilities
Factory Default
Exit
143311 (H)
