Step 2. Mount the socket on the bottom of the right side panel( A2) with 2 M3 x 16
Hex Counter- sunk-head screws and M3 hex nut.
on the bottom of the
Step 3. Thread the wires connected to the switch through another hole
right side panel( A2) from outside to inside and connect the 3 wires to the socket, do
not mix them up.
M3 x 12mm screws.
Step 3. Mount the PSU on the right side panel with 4
Take a look at the video here.

25. Mount the control board.

Part name Part ID Required number pic
1
Control board kit 62
No.
