Two Z Motor Mount Assembled To The Main Frame(A1) - Geeetech Prusa I3 X Building Instructions

Motor holder
(right)
Motor Holder
support
Motor Holder
support
Assemble the motor holder ((right) and the motor holder support together, screw it up
with 3 M3 x 16mm screw and M3 Square nut.
Watch the video here.

9. Two Z motor mount assembled to the main frame(A1)

Part name
M3 x 16mm screw
M3 Square nut
Main frame
Shenzhen GETECH CO.,LTD
GEEETECH
No.A5
No.A6
No.A7
Part ID Required number
No.23
No.16
No.A1
1
1
1
6
6
1
pic
