Step 3. Mount the endstop
Part name
M2.5 x 16mm
screw
M2.5 hex nut
End stop
Left bearing top
plate
Mount the endstop on the Left bearing top plate with two M2.5 x 16mm screw and
Shenzhen GETECH CO.,LTD
GEEETECH
Part ID
Required number
No. 20
No. 11
No.52
No.A17
2
2
1
1
pic
\
