Side Panel Assembly - Geeetech Prusa I3 X Building Instructions

Mount the to assembled Z motor mount to A1 with M3 x 16mm screw and M3 Square
nut.
*Be very careful here, if you can not insert it into the hole you can loose the screw on
the motor mount and try again.
Watch the video here.

10. Side panel assembly

Part name
M3 x 16mm screw
M3 Square nut
M3 washer
Side panel(left)
Side panel(right)
Fix the side panel on A1 with M3 x 16mm screw, M3 Square nut and M3 washer.
Shenzhen GETECH CO.,LTD
GEEETECH
Part ID Required number
No.23
No.16
No.7
No.A2
No.A3
6
6
6
1
1
