X axis belt holder
* Note the direction
Step 5. Fix the linear bearing SCS8LUU.
Part name
linear bearing
SCS8LUU
M4x16mm screw
M3 x 16mm screw
Shenzhen GETECH CO.,LTD
GEEETECH
No.A 20
Part ID
Required number
No. 37
No. 30
No. 23
1
1
4
4
pic
\
