Description
Port/Connector (Female end)
2
1
A
B
Illustration 4.12 Female Connector
Female end (output): M23, internal thread
Pin Description
Power
1 –UDC
2 PE
3 +UDC
4 +24 V Safety (STO)
CAN
A CAN GND
B CAN Low
C CAN High
D CAN V
Table 4.7 M23 Connector/Wire Assignment for Loop Cable and Feed Cable
®
VLT ISD 410 Servomotor Operating Instructions
4
3
D
C
Wire Coding
1 Black
Green/Yellow
2 Black
3 Black
Black
White
Blue
Red
cc
®
MG75D102 - VLT is a registered Danfoss trademark
Ø in mm Comments
2
1/2.5 –
-/1 STO, referenced to –UDC
Twisted pair A
Twisted pair B
0.5
Twisted pair B
Twisted pair A
4 4
