Connection Cables/Cabling - Danfoss VLT ISD 410 Operating Instructions Manual

Description

4.3 Connection Cables/Cabling

The ISD servo motors are connected by hybrid cables (loop
cables). The hybrid cables contain the 300 V DC supply
voltage lines and the CAN bus signal lines.
The loop cables interconnect the servomotors, and a feed
cable provides the supply voltage from the connection box
to the first servomotor.
4 4
1
Failure
Warning
Output (300V) OK
Output (90V) OK
Stand-By
90V_OK
300V_OK Signal Outputs
Error
Enable
300 Signal Inputs
10A
8
Illustration 4.7 Motor Daisy-chaining (Looping)
Number Item
1 Ethernet
2 CAN line
3 Encoder line
4 CAN terminator Connector with terminating resistor –
5 Loop cable
6 Feed cable
7 DC cable
8 AC feed
Table 4.5 Connection Cables
16
®
VLT ISD 410 Servomotor Operating Instructions
Failure
Warning
Output (300V) OK
Output (90V) OK
Stand-By
7 6
Cable Type/Item
Ethernet cable
CAN cable
Encoder cable
Hybrid cable (DC & CAN)
Hybrid cable (DC & CAN)
Single wire
Single wire
MG75D102 - VLT
Hybrid cables are available in various lengths and are
designed to be compatible with drag chains.
2
5
Cable Width
2
4 x 2x 0.27mm , shielded twisted pairs
(CAT 5)
2
4 x 0.25 mm
4 x 0.25 mm 2
2 2
1 mm /2.5 mm
2 2
1 mm /2.5 mm
1.5 mm 2
2
1.5 mm
®
is a registered Danfoss trademark
3
4
Flexible ?
X
–
–
–
2
X ( only with 2.5 mm cable)
2
X ( only with 2.5 mm cable)
–
–
