Programming

5.6 Error messages

5.6 Error messages
The error messages of the function block are described in the following table (refers to the
output parameter "out.swError"):
Table 5- 10 List of the error messages at the output of the function block
Bit Requires Description
No. acknowledg-
ment
0 No Hardware (communication module) not
ready
1 Yes Invalid configuration (in.evseCfg)
66
Remark
The communication module does not report back, for
example, because of a PROFINET fault or a fault of the
ET 200SP backplane bus communication.
The frequency converter is ramped down in a controlled
manner.
An invalid configuration exists at the function block input.
Possible causes of the fault:
"evseID" is greater than "32"
•
"maxCurrentInAmpere" is greater than "minCurrentIn-
•
Ampere"
"maxVoltageInVolt" is less than "minVoltagetInVolt"
•
"maxSwitchTimeBreaker" is less than 0 ms
•
"maxSwitchTimeHwState" is less than 0 ms
•
"maxTimeInvalidParamsOrRampCharge" is less than
•
0 ms
"maxTimeRampUpDown" is less than 0 ms
•
"maxTimeInvalidParamsOrRampCharge" is less than
•
"maxTimeRampUpDown"
"cableCheckCurrentInAmpere" is greater than "max-
•
CurrentInAmpere"
"preChargeCurrentInAmpere" is greater than" max-
•
CurrentInAmpere"
"stopChargingCurrentInAmpere" is greater than
•
"maxCurrentInAmpere"
If the voltage "maxExtVoltageInVolt" is greater than
•
"maxVoltageInVolt" for the check "extVoltageCheck-
IsSupported"
If the resistance "shuntValueInOhm" is "0" for the
•
check "shuntIsUsed"
"cableCheckCurrentInAmpere" is less than or equal to
•
"maxCableCheckLeakCurrentInAmpere"
"maxCableCheckLeakCurrentInAmpere" is greater
•
than "maxCurrentInAmpere"
"supportedEnergyTransferTypes" is not equal to "Bit
•
2" or "Bit 3" (The function block DIN_70121 only sup-
ports DC_core (Bit 2) and DC_extended (Bit 3))
Technology module TM ECC PL ST (6FE1242-6TM20-0BB1)
Manual, 07/2019, A5E43919893B-AA
