Siemens SIMATIC ET 200SP Equipment Manual

Siemens SIMATIC ET 200SP Equipment Manual

Digital output module dq 16x24vdc/0.5a st
Hide thumbs Also See for SIMATIC ET 200SP:
Table of Contents

Advertisement

Quick Links

Download this manual
SIMATIC
ET 200SP
Digital output module
DQ 16x24VDC/0.5A ST
(6ES7132-6BH01-0BA0)
Equipment Manual
01/2025
A5E03574420-AE
Introduction
Industrial cybersecurity
Product overview
Connecting
Parameters/address space
Interrupts/diagnostic alarms
Technical specifications
Parameter data record
1
2
3
4
5
6
7
A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIMATIC ET 200SP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens SIMATIC ET 200SP

Summary of Contents for Siemens SIMATIC ET 200SP

  • Page 1 Introduction Industrial cybersecurity SIMATIC Product overview ET 200SP Digital output module Connecting DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) Parameters/address space Equipment Manual Interrupts/diagnostic alarms Technical specifications Parameter data record 01/2025 A5E03574420-AE...

  • Page 2: Legal Information

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Table of contents Introduction............................ET 200SP Documentation Guide..................1.1.1 Information classes ET 200SP.................... 1.1.2 Basic tools........................1.1.3 MultiFieldbus Configuration Tool (MFCT)................1.1.4 SIMATIC Technical Documentation..................10 Industrial cybersecurity........................12 Introduction to industrial cybersecurity................12 Cybersecurity information....................12 Product overview..........................13 Properties ........................

  • Page 4: Introduction

    Purpose of the documentation This manual supplements the system manual ET 200SP distributed I/O system (https://support.automation.siemens.com/WW/view/en/58649293). Functions that generally relate to the system are described in this manual. The information provided in this manual and in the system/function manuals supports you in commissioning the system.

  • Page 5: Et 200Sp Documentation Guide

    This arrangement enables you to access the specific content you require. You can download the documentation free of charge from the Internet (https://support.industry.siemens.com/cs/ww/en/view/109742709). Basic information The System Manual describes in detail the configuration, installation, wiring and commissioning of the SIMATIC ET 200SP distributed I/O system.

  • Page 6: General Information

    Product Information takes precedence over the device and system manuals. You can find the latest Product Information on the ET 200SP distributed I/O system on the Internet. (https://support.industry.siemens.com/cs/de/en/view/73021864) Manual Collection ET 200SP The Manual Collection contains the complete documentation on the SIMATIC ET 200SP distributed I/O system gathered together in one file.

  • Page 7: Basic Tools

    With the TIA Selection Tool , you can generate a complete order list from your product selection or product configuration. You can find the TIA Selection Tool on the Internet. (https://support.industry.siemens.com/cs/ww/en/view/109767888) SIMATIC Automation Tool You can use the SIMATIC Automation Tool to perform commissioning and maintenance activities on various SIMATIC S7 stations as bulk operations independent of TIA Portal.
  • Page 8 You can find SIEMENS PRONETA Basic on the Internet: (https://support.industry.siemens.com/cs/ww/en/view/67460624) SIEMENS PRONETA Professional is a licensed product that offers you additional functions. It offers you simple asset management in PROFINET networks and supports operators of automation systems in automatic data collection/acquisition of the components used through various functions: •...

  • Page 9: Multifieldbus Configuration Tool (Mfct)

    MultiFieldbus- and DALI-devices. In addition, the MFCT offers convenient options for mass firmware updates of ET 200 devices with MultiFieldbus- support and reading service data for many other Siemens devices. Functional scope of the MFCT • MultiFieldbus configuration:...

  • Page 10: Simatic Technical Documentation

    Online Support: Industry Online Support International https://support.industry.siemens.com/cs/ww/en/view/109742705 Watch this short video to find out where you can find the overview directly in Siemens Industry Online Support and how to use Siemens Industry Online Support on your mobile device: Quick introduction to the technical documentation of automation products per video ( https://support.industry.siemens.com/cs/us/en/view/109780491...

  • Page 11: Application Examples

    Manuals, characteristics, operating manuals, certificates • Product master data You can find "mySupport" on the Internet. (https://support.industry.siemens.com/My/ww/en) Application examples The application examples support you with various tools and examples for solving your automation tasks. Solutions are shown in interplay with multiple components in the system - separated from the focus on individual products.

  • Page 12: Industrial Cybersecurity

    Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to...

  • Page 13: Product Overview

    Product overview Properties Article number 6ES7132-6BH01-0BA0 (number in package unit: 1 unit) 6ES7132-6BH01-2BA0 (number in package unit: 10 units) View of the module 1 6 x 2 4 V D C /0 .5 A D IA G 24 V D C M A X .
  • Page 14 • Labeling strips • Color-coded labels • Reference identification label • Shield connection See also You can find more information on accessories in the ET 200SP Distributed I/O System (https://support.automation.siemens.com/WW/view/en/58649293) System Manual. Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) Equipment Manual, 01/2025, A5E03574420-AE...

  • Page 15: Connecting

    This section contains the pin assignment for the module. You can find information on wiring the BaseUnit in the ET 200SP Distributed I/O System (http://support.automation.siemens.com/WW/view/en/58649293) System Manual. NOTE The load group of the module must begin with a light-colored BaseUnit. Also keep this in mind during configuration.
  • Page 16 You can also connect the ground and functional grounding via a potential distribution module (PotDis module) or AUX terminals. More information on potential distribution modules is available in the BaseUnits Equipment Manual (https://support.industry.siemens.com/cs/ww/en/view/59753521). NOTE You can use and combine the different connection options for all channels.

  • Page 17: Block Diagram

    Connecting 4.2 Block diagram Block diagram This section contains the schematic circuit diagram of the module. Figure 4-1  Schematic circuit diagram Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) Equipment Manual, 01/2025, A5E03574420-AE...

  • Page 18: Parameters/Address Space

    Parameters/address space Parameters Parameters for DQ 16x24VDC/0.5A ST You can specify the module properties with various parameters in the course of your STEP 7 configuration. The table below lists the configurable parameters. The efficiency range of the configurable parameters depends on the type of configuration. The following configurations are possible: •...
  • Page 19 Parameters/address space 5.1 Parameters Parameters Range of values Default Parameter Scope with configuration soft­ reassignment ware, e.g. STEP 7 (TIA Portal) in RUN GSD file GSD file PROFINET IO PROFIBUS DP  Channel activated • Disable Enable Channel Channel • Enable Reaction to CPU STOP •...

  • Page 20: Declaration Of Parameters

    Specify on which slot a light-colored BaseUnit with supply voltage feed or a dark BaseUnit is located (see ET 200SP Distributed I/O System (https://support.industry.siemens.com/cs/ww/en/view/58649293) System Manual). All additional I/O modules of this potential group are plugged into dark-colored BaseUnits. You take the potential of the self-assembling voltage buses P1, P2 and AUX from the left neighbor.

  • Page 21: Address Space

    (0 = value is incorrect). You can find more information on evaluating the value status in the ET 200SP Distributed I/O System (https://support.industry.siemens.com/cs/ww/en/view/58649293) System Manual. Address space for configuration as 1 x 16-channel DQ 16x24VDC/0.5A ST V0.0 The figure below shows the address space assignment for configuration as a 1 x 16-channel module without value status.
  • Page 22 Parameters/address space 5.3 Address space Address space for configuration as 1 x 16-channel DQ 16x24VDC/0.5A ST V0.0, QI The figure below shows the address space assignment for configuration as a 1 x 16-channel module with value status. You can freely assign the start address for the module. The addresses of the channels are derived from the start address.

  • Page 23: Interrupts/Diagnostic Alarms

    Interrupts/diagnostic alarms Status and error display LED display The figure below shows the LED displays (status and error displays) of the module: ① DIAG (green/red) ② Channel status (green) ③ PWR (green) Figure 6-1  LED display Meaning of the LEDs The meaning of the status and error messages is described in the following tables. You will find remedial measures for diagnostics alarms in the Diagnostic messages (Page 26) section.
  • Page 24 Interrupts/diagnostic alarms 6.1 Status and error display DIAG LED Table 6-1  DIAG LED fault display DIAG LED Meaning Backplane bus supply of the system is interrupted or switched off. Module not configured Flashes Module parameters assigned and no module diagnostics available Module parameters assigned and module diagnostics available Flashes LED channel status...

  • Page 25: Interrupts

    Interrupts/diagnostic alarms 6.2 Interrupts Interrupts The digital output module DQ 16×24VDC/0.5A ST supports diagnostic interrupts. Diagnostics interrupts The module generates a diagnostic interrupt for the following events: • Short circuit • Wire break • Parameter assignment error • Supply voltage missing You can find detailed information on events in the STEP 7 online help. Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) Equipment Manual, 01/2025, A5E03574420-AE...

  • Page 26: Diagnostic Messages

    Interrupts/diagnostic alarms 6.3 Diagnostic messages Diagnostic messages A diagnostic message is generated and the DIAG-LED flashes red on the module for each diagnostics event. You can read out the diagnostics alarms, for example, in the diagnostics buffer of the CPU. You can evaluate the error codes with the user program. NOTE Wiring two outputs in parallel When connecting two outputs in parallel for redundant control of a load, the channel...

  • Page 27: Technical Specifications

    Technical specifications Technical specifications of the DQ 16x24VDC/0.5A ST The following table lists the technical specifications on the issue date. You will find a data sheet including daily updated technical specifications on the Internet (https://support.industry.siemens.com/cs/ww/en/pv/6ES7132-6BH01-0BA0/td?dl=en). Article number 6ES7132-6BH01-0BA0 General information  ...
  • Page 28 Technical specifications 7.1 Technical specifications Article number 6ES7132-6BH01-0BA0 Supply voltage   Rated value (DC) 24 V permissible range, lower limit (DC) 19.2 V permissible range, upper limit (DC) 28.8 V Reverse polarity protection Input current   Current consumption, max. 30 mA; without load output voltage / header  ...
  • Page 29 Technical specifications 7.1 Technical specifications Article number 6ES7132-6BH01-0BA0 Load resistance range   • lower limit 48 Ω upper limit 12 kΩ • Output current   • for signal "1" rated value 0.5 A • for signal "1" permissible range, max. 0.5 A • for signal "0" residual current, max. 0.1 mA Output delay with resistive load  ...
  • Page 30 Technical specifications 7.1 Technical specifications Article number 6ES7132-6BH01-0BA0 Diagnoses   • Monitoring the supply voltage Wire-break Yes; Module-wise • • Short-circuit to M Yes; Module-wise • Short-circuit to L+ Yes; Module-wise • Group error Diagnostics indication LED   • Monitoring of the supply voltage Yes;...
  • Page 31 Technical specifications 7.1 Technical specifications Residual current for signal state "0" NOTE Residual current for signal state "0" Due to the "Diagnostics: Wire break" function, there is a low level of residual current in the "0" signal state at the output, which may cause the display diodes to flicker. This residual current does not depend on the setting for the "Diagnostics: Wire break"...

  • Page 32: Dimension Drawing

    5 mH 10 mH 30 mH 50 mH 100 mH 300 mH 500 mH 1152 mH Figure 7-2  Maximum switching frequency Dimension drawing See Equipment Manual ET 200SP BaseUnits (https://support.industry.siemens.com/cs/ww/en/view/59753521) Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) Equipment Manual, 01/2025, A5E03574420-AE...

  • Page 33: Parameter Data Record

    Parameter data record Parameter assignment and structure of parameter data record The data record of the module has an identical structure, regardless of whether you configure the module with PROFIBUS DP or PROFINET IO. With data record 128, you can reparameterize the module in your user program, regardless of your programming. This means that you can use all the functions of the module even if you configured it via PROFIBUS-GSD.

  • Page 34: Header Information

    Parameter data record A.1 Parameter assignment and structure of parameter data record Structure of data record 128 NOTE Channel 0 includes the diagnostics enable for the entire module. Figure A-1  Structure of data record 128 Header information The figure below shows the structure of the header information. Figure A-2  Header information Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) Equipment Manual, 01/2025, A5E03574420-AE...

  • Page 35: Error Codes

    Parameter data record A.2 Error codes Parameters The figure below shows the structure of the parameters for channels 0 to 15. You enable a parameter by setting the corresponding bit to "1". Figure A-3  Structure byte x to x+1 for the channels 0 to 15 Error codes Error transferring the data record The module always checks all the values of the transferred data record.
  • Page 36 Parameter data record A.2 Error codes Error code in STATUS parameter Meaning Solution (hexadecimal) Byte 0 Byte 1 Byte 2 Byte 3 Module not accessible • Check station. • Plug the module in correctly. • Check parameters of the WRREC block. Header error (version or specified bits incor­...
