Solar-Log™ Pm; 6-Pin Pm+ Interface - Solar-Log 2000 Installation Manual

Current transformers from Solare-Datensysteme GmbH
Solare-Datensysteme offers the following current transformers that are specially tailored to the Solar-
Log™ Meter:
Current transformer
Name
Solar-Log™ CT 16 A
Solar-Log™ CT 100 A-c
Solar-Log™ CT 100 A-o
7�3 Solar-Log™ PM+

6-pin PM+ interface

PM+
PIN
1
2
3
4
5
6
Description
Current measurement 16 A, transformer:
16A/200mA
Current measurement 100 A, transformer:
100A/200mA
sealed transformer
Current measurement 100 A, transformer:
100A/200mA
open transformer (folding mechanism)
Assignment
+5V
D_IN_1
D_In_2
D_In_3
D_In_4
+5V
Article
Number:
255639
255640
255638
Description
Control voltage for active
power control
Control input 1
Control input 2
Control input 3
Control input 4
Control voltage for reac-
tive power reduction
Optional Connections
25
