2-9-7 Trigger channel
Sets the target output when the trigger for starting storage is set.
Storage starts once the selected output meets the necessary conditions.
• Options: Ch1 / Ch2 / Ch3 / Ch4
• Default value: Ch1
2-9-8 Start position
Specifies by how much the start of storage should be shifted when the start condition is satisfied.
The unit is the number of samplings.
• Positive value: Delays by the specified number of samplings and then starts storage. (Delay trigger)
• "0": Starts storage the instant the condition is satisfied.
• Negative value: Backs up by the specified number of samplings and then starts storage. (Pre-trigger)
• Input range: ±50000
• Default value: –300
2-9-9 Repeat
Sets the operation to perform after the storage operation has been performed for the number of data items
set under "Quota."
• OFF: Sets "Status" to "Stopped" after the storage operation completes.
• ON: Sets "Status" to "Trigger standby" after the storage operation completes.
MEMO
When "Repeat" is set to ON, the CDX Series will resume storage operation immediately if the trigger conditions are met
after the storage operation has finished.
2-9-10 Stored Data
Displays the details of the most recent storage data as a waveform.
2-9-11 Storaged data list
Displays the saved (stored) data as a list. The most recent data is displayed at the bottom of the list.
Click the file name (the part displayed with the extension *.csv) to download that file immediately.
• Delete All: Deletes all the data saved (stored) on the unit.
Storage Screen
