85 mm type
„
29
15
Measurement range
Specular reflection installation
Optical axis of receiver
20°
Optical axis of emitter
81.5±10.0
150 mm type
„
29
15
Measurement range
Optical axis of receiver
20°
Optical axis
of emitter
85 ±20
86.1
77.7
4.2 9.9
Optical axis of receiver
13°
Optical axis of emitter
150±40
75
66.6
4.2
4.2
ø
2- 4.3
8-pole M12 plug connector
75
66.6 4.2
4.2
ø
2- 4.3
8-pole M12 plug connector
Link indicator (green)
Power indicator
(orange/green/blue/red)
Link indicator (green)
Power indicator
(orange/green/blue/red)
Dimensions
