1-1 System Configuration

In addition to being usable as a standalone device, the product can be used connected to a CDA Series
displacement sensor control unit.
CDX Series
Open-ended cable
• Power
• External input
CDA Series
3. Configuration of Settings When Using with CDA Series
System Configuration
1-2
Head extension cable
PC
Branch
connector
PLC
Ethernet cable
Hub, router
CDA cable
• Power
• Analog output
• I/O
*CDX Series products do not support CC-link communication.
2. Web Settings Screen and
Function Details
4. Ethernet Communication
• Various settings
• Acquiring measurements
• Acquire storage data
