• Auto Bottom: The minimum value from when the hold reset input is detected until the present will be
output.
Measurement
value
Hold ON
reset
OFF
• Peak-to-Peak: The value of the maximum value - the minimum value from when the hold reset input is
detected until the present will be output.
Hold ON
OFF
• Normal: The measured value is maintained while the hold reset input is applied.
Measurement
value
Hold ON
OFF
• Default value: OFF
Peak-to-peak hold
measurement value
P(1)
B(1)
Sampling period
Internal measurement value
Auto bottom hold measurement value
Internal
measurement value
P(2)
P(1)−B(1)
P(2)−B(2)
B(2)
Sampling period
