OPTEX FA D Series Instruction Manual

Ramco Innovations
Photoelectric Sensor
D SERIES
・ DM-18T□□
INSTRUCTION MANUAL
Confirm if the item meets your needs.
●
Before the use, you should first thoroughly read
●
this manual and operate correctly as mentioned.
You should keep this manual at hand for proper use.
●
Iuput/Output Circuit Design
NPN
PNP
Pin configuration
① 10〜30V DC
② Bank
③ 0V
④ Control output
Parts Name
laser emitter indication
output indicator
digital display panel
Up button
foreside
Teach / Enter
Down button
backside
Turn the connector as Black Arrow
indicates, otherwise you will damage the
connector. The damage will be unrepairable.
Status Indicator
Color mode
Indicate matching level
RUN mode compare to teaching
color.
Indicate thresh lebel.
Thresh level
After teaching, thresh
adjust mode
lebel is 80.
Function
Indicate selectable function.
select mode
Warnings
For safety use
○ Warm-up period (approx. 100 msec) must be secured.
○ Should avoid to use sensor outside or at the place where receiver is
influenced by environmental illuminance directly.
○ Gaps in indicated values and detection features are possible due to dispersion.
○ Use of controls or adjustments or performance of procedures
other than the specified herein may result in hazardous radiation exposure.
！Must not use this item as safety equipment
for the purpose of human body protection.
Specification
Type
Scanning range
Supply voltage
Current consumption
Response time
Timer
Light source
Indicator
Digital indicator
Control output
Operation mode
Teaching
Bank
Protection category/ material
Weight
Functions
Reset
(rS)
Display ON/OFF
(dP)
Response time
(rP)
Timer
(dY)
＊ For connector type only
Mark mode
indicates amount
Indicate remission
L.ON/D.ON
of incoming light.
(Ld)
Indicate thresh level.
After teaching, thresh
lebel is 50.
Color/Mark
(CI)
Bank
(ch)
www.optex-ramco.com
Cable type
DM-18T (N,P)
Mark mode： 0.25/0.5/1.2ms selectable Color mode： 0.8/1.6/4ms selectable
Off delay / On delay / One shot delay (10msec increment :0-1,000msec, 1sec increment for 1-10sec)
Mark mode： 1 color (selected by teaching) Color mode： RGB automatic selection
Output indicator（ Orange LED) , Stable indicator (Green LED)
7 segment, 3 digits LED Green： Bank No. Red： Function, Status
NPN/PNP Open collector 100mA max./ DC30V
Mark mode： 2 point teach／Auto teach Color mode： １ point teach
IEC IP67 / Housing : heat-resistant ABS(antibacterial） Front cover : PMMA Button : TEEE
cable type: about 75g / connector type: about 20g
RUN mode
or
T
T
T
T
T
T
T
Response time, L.ON/D.ON, Color/Mark mode can be set for each Bank.
Phone 800-280-6933
M8 Connector type
DM-18TC (N,P)
18mm ± 2mm
DC10 〜 30V including 10% ripple (P-P)
40mA max.
R (634nm) / G (517nm) / B (469nm)
Light ON / Dark ON selectable
８ bank
Press teach button
T
Press + button
Press - button
Yes
No
Display OFF
Display ON
Low (Resolution : High)
Middle (Resolution : Middle)
High (Resolution : Low)
T
One shot
ON delay
OFF delay
Without timer
D.ON
L.ON
Mark mode
Color mode
Bank '0'
Bank '7'
Press + button
during more than 2 s.
Press - button
during more than 2 s.
T
T
T
0
10ms
Every
10 ms
T
990ms
1 s
Every
1 s
10 s
T
T
T
RUN mode
