OPTEX FA E Series Instruction Manual

Photoelectric Sensor
E series
EＴ-500□□□ EＬ-15□□□
EＤ-100□□□ EＬ-08□□□
EＬ-30□□□
INSTRUCTION MANUAL
●Thank you for purchasing the E series.
● P lease read this manual before using the sensor, and retain it for future
reference.
● C arefully read and understand the safety precautionsbefore operation.
T he important information is provided to protect your health and property.
Spesifications
Model
Cable
M8 4pin connector
M8 3pin connector
Detecting distance
Supply voltage
Current consumption
Response time
Hysteresis
Control output
Operation mode
Beam size
Indicator
Operating temp. / humidity
Storage temp. / humidity
Ambient light
Protection category
Material
Input and output circuit diagrams
NPN output
12 〜 24Ｖ DC
Control output
0V
PNP output
12 〜 24Ｖ DC
Control output
0V
Connector pin No. Connector pin No.
４pins 3pins
Control output ②
④
① ③
① ③
0V
12〜24V DC
12〜24V DC
Dimensions
Through beam
Power ON indicator (red）
Emitter lens
φ2.5 2core 2m cable
M8 3/4pin connector
φ2.5 150mm cable
Through beam type
ET-500NL/ND/PL/PD ED-100NL/ND/PL/PD
ET-500NL4/ND4/PL4/PD4 ED-100NL4/ND4/PL4/PD4 EL-30NL4/ND4/PL4/PD4 EL-15NL4/ND4/PL4/PD4 EL-08NL4/ND4/PL4/PD4
ET-500NL3/ND3/PL3/PD3 ED-100NL3/ND3/PL3/PD3 EL-30NL3/ND3/PL3/PD3 EL-15NL3/ND3/PL3/PD3 EL-08NL3/ND3/PL3/PD3
500ｍｍ
Emitter：14mA max.
Receiver：16mA max.
−
E□-□□□N□□：NPN Open collector E□-□□□P□□：PNP Open collector 50mA max. ／ 24V DC
φ140mm/Distance 500mm φ60mm/Distance 100mm
Attachment
With attached nut
Washer
Screw
M2(Length 8mm)
Control output
Under 3mm
Tightening torque need to be under 0.15N . m.
0V
Through beam
Emitter Receiver
Stable indicator (green）
Output indicator （ orange)
Receiver lens
φ2.5 150mm cable
Unit（mm）
CAUTION
CAUTION
This product cannot be used as a safety device to protect human body.
Diff use ref. type
Long
EL-30NL/ND/PL/PD
100ｍｍ 5 〜 30ｍｍ
12 〜 24V DC （ripple 10％ max.）
0.5ms max.
White paper : 10%(EL-08 and EL-15),15%(EL-30 and ED-100)
E□-□□□□L□：Light ON E□-□□□□D□：Dark ON
φ20mm/Distance 30mm
Stable indicator ： Green LED Output indicator ： Orange LED
ｰ25 〜 +55℃ /35 〜 85%RH（No condensation or freezing）
ｰ40 〜 +70℃ /35 〜 95%RH（No condensation or freezing）
3,000 lx（Incandescent light） 10,000 lx（Sunlight）
IP67
PC
Diffuse/Convergent
With a shave at
attaching position
Spring washer
Nut
M2×0.4
Depth 7mm
φ2.5 3core cable
M8 3/4pin connector
Indicates a possible hazard that may result in personal
injury or property damage if the product is used without
observing the stated instructions.
Mandatory Requirements
● T his product is not an explosion-proof construction. Do not
use the product under flammable explosive gas or liquid
environment.
● N ever fail to turn OFF the power supply when wiring or
disconnecting.
Operating Precautions
● The sensor performance may depend on the individual units.
● W ipe off dirt on the emitting/receiving parts to maintain
correct detection. Also, avoid direct impact on the product.
Convergent type
Middle
EL-15NL/ND/PL/PD
2 〜 15ｍｍ
20mA max.
φ10mm/Distance 15mm
Stable indicator (green）
Output indicator （orange)
Receiver lens
φ2.5 3core cable
φ2.5 150mm cable
● T he product specification may change without notice
for improvement.
→
http://www.optex-fa.com/rohs_cn/
Head office： 600-8815 Kyoto, Shimogyo, Awata Chudoji 93, Japan
91 Chudoji Awata-cho Shimogyo-ku Kyoto 600-8815 Japan
TEL. +81-(0)75-325-2920 FAX. +81-(0)75-325-2921
TEL: +81-(0)75-325-2920 FAX: +81-(0)75-325-2921
Website
Short
EL-08NL/ND/PL/PD
3 〜 8ｍｍ
φ10mm/Distance 10mm
Emitter lens
M8 3/4pin connector
Unit（mm）
http://www.optex-fa.com
Rev.1.2
