Sutter Instrument MPC-78 Assembly Manual page 6

5
Connect Electronics To MPC-78
Simply connect the motorized manipulator, controller, and ROE
together using the cables provided. Quick step guide below:
• Connect power cord to MP-200 controller.
• With the power off, connect the ROE-200 input box and the
MPC-200 controller using the RJ-45 8-conductor cable. Insert
the "CONTROLLER" output on the back of the ROE-200 and
the "COMMAND INPUT" on the back of the controller.
• With the power OFF, run a DB-25 cable from the motorized
mechanical to the DB-25 connectors marked "MANIPULATOR
A" or "MANIPULATOR B" on the back of the controller.
• Connecting electronics completed.
Assembly Guide
Large Moving Stage Platform
1 Assemble Stands
2 Attach Manipulators
3 Square Manipulators
4 Orientation of Stands
5 Connect Electronics 5 Connect Electronics
6 6 Centering Routine
7 7 Attach Top Plate
8 8 Adjust Height
9 9 Testing
10 Support
