Sutter Instrument MPC-78 Assembly Manual page 2

1
Assemble Stands
Your MP-78 is shipped to you with all the necessary hardware to
complete assembly and set-up. Follow this and the next eight steps
to complete the set up of your large moving stage platform.
• Attach base plates using (4) 5/16x1/2 screws each found in
hardware bag labeled "Base Plate Screws".
• The black cap wing nut screws face forward.
Assembly Guide
Large Moving Stage Platform
(8) 5/16 x 1/2 IN
