Sutter Instrument MPC-78 Assembly Manual page 10

9
Testing
Complete the assembly by attaching the specified insert and testing
the movement. A trial run of both the "X" and "Y" full path of travel
is recommended. The goal is to confirm that the plate movement is
unobstructed and the insert is centered under your objective. Follow
the steps below:
• Manually dial the "X" and "Y" control knobs one at a time.
• Drive the motorized plate its full range of travel which is 12500
microns in each direction.
• Note: the unit will stop automatically at each end of travel.
Assembly Guide
Large Moving Stage Platform
1 Assemble Stands
2 Attach Manipulators
3 Square Manipulators
4 Orientation of Stands
5 Connect Electronics
6 Centering Routine
7 Attach Top Plate
8 Adjust Height
9 Testing 9 Testing
10 Support
