9460/9460KP/9462/9462KP System Manual

Parallel Port Connector (LPT1)

LPT1 is a 25-pin connector.
C-2
Pin Signal
1A STROBE
2A PD(0)
3A PD(1)
4A PD(2)
5A PD(3)
6A PD(4)
7A PD(5)
8A PD(6)
9A PD(7)
10A PACK
11A PBUSY
12A PE
13A SELECT
14A AUTOFEED
15A PERROR
16A INIT
17A SELIN
18A GND
19A GND
20A GND
21A GND
22A GND
23A GND
24A GND
25A GND
