Dual Usb Connector (Usb1); Parallel Port Connector (Lpt1) - Xycom 3600 Series 3612T User Manual

3600 Series Flat Panel Industrial PC

Dual USB Connector (USB1)

The following table lists the signal definitions for the two USB connectors.
Pin
1A
2A
3A
4A

Parallel Port Connector (LPT1)

The following table shows the signal definitions for the DB-25 LPT1 connector.
Pin
10
11
12
13
Table C - 3. Dual USB Pinout
Description
5VFUSE
USBP0–
USBP0+
GND
Table C - 4. Parallel Connector Pinout
Signal
1 STROBE
2 PD(0)
3 PD(1)
4 PD(2)
5 PD(3)
6 PD(4)
7 PD(5)
8 PD(6)
9 PD(7)
PACK
PBUSY
PE
SELECT
Pin Description
1B 5VFUSE
2B USBP1–
3B USBP1+
4B GND
Pin Signal
14 AUTOFEED
15 PERROR
16 INIT
17 SELIN
18 GND
19 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 GND
66
Appendix C – Pinouts
142214 (F)
