9460/9460KP/9462/9462KP System Manual
Feature
Display
Diagnostic LEDs
Function and User-Defined Keys
Numeric/Cursor Control Keypad
F/A Key (Contrast Control)
PF10 Key (Keypad Configuration Key)
Keyboard Port (9460KP/9462KP)
(front access)
3-4
Description
The 9460KP/9462KP comes with a 10.4-inch (640 x 420) STN
or TFT flat-panel display or a 12.1-inch SVGA (800 x 600) STN
or TFT flat-panel display.
The 9460KP/9462KP features status LEDs on the front panel,
which allow you to monitor system operation. Following is a de-
scription of the LEDs and what it means when they're lit:
Power Lit when the system has power
Disk Lit when the computer is accessing the disk drive
COM Lit when there is communication activity on one of the
serial ports, including communication between the com-
puter module and the touch screen (if on COM2) or a se-
rial mouse.
Input Lit when the unit has a touch screen; the LED gets
brighter when a touch input is detected or a key is
pressed.
F/A key Indicates the keypads are in alpha mode
These 38 relegendable function keys (76 using the F/A keys)
provide easy access to familiar routines. (F/A keys can be used
for alpha and symbol entry). See the Customizing Keypad In-
serts section in this chapter for details on customizing your key-
pad inserts.
The purpose of data entry keypads are for entering data and
moving the cursor.
If the LED is lit, alpha characters are returned. While holding
down the F/A key and pressing the cursor control keys, contrast
can be adjusted (STN displays only).
This key reconfigures your keypad.
The 9460KP/9462KP provides both front and rear accessible
PS/2 keyboard connectors. The front accessible connector is
located on the lower right side of the front panel. The rear ac-
cessible connector is located on the side of the unit.
Note: Only one keyboard port on the 9460KP/9462KP can be
used at a time.
Note: The installation of the touch screen driver determines
whether a second pointing device will function correctly. If you
are using a mouse with a touch screen, please review the
Touch Screen Driver Installation instructions.
