Download Menu

Any macro set previously programmed is overwritten when you select
Download.
Download sends the set of keypad macros to the keyboard controller. The macro set must
reside in memory before it can be downloaded. A checksum is calculated during transmis-
sion and an error message displays if an error occurs.
As the macro is sent, keyboard controller programs its EEPROM with the new macros
which become the new key definitions for the keypad.

Utilities Menu

When Utilities is selected, a menu bar displays four choices: Func Lock ON, Func
Lock OFF, Clear EEPROM, and Exit.

Func Lock ON

Not available on the 9460KP/9462KP.

Func Lock OFF

Not available on the 9460KP/9462KP.

Clear EEPROM

Erases the EEPROM memory. This clears the entire keypad macro set. After using this
feature, the unit should be turned off and then on. This will initialize the EEPROM with
the default settings.

Exit

Returns to the Main Menu.

Codes

Special keyboard controller codes replace the standard IBM scan codes for 101-key key-
board enhanced keys in macros that use these keys. The special scan codes are listed in
the table below:
Chapter 4 – Programmable Keypad Utility Program (9460KP/9462KP)
Note
4-7
