9460/9460KP/9462/9462KP System Manual
12. Lift the cover. Note how the wiring on the bulb assembly is routed.
13. Pop the wires out of the wire guides and remove the bulb assembly.
14. Insert the new bulb assembly. Use care as the bulbs are very fragile.
15. Route the wiring to the original position.
16. Replace the cover, and insert and tighten the bulb assembly cover screws.
17. Repeat steps 11 through 16 to replace the second bulb assembly.
18. Reverse steps 1 through 10 to reassemble the unit.
D-2
Figure Appendix D -1. Model #KCS6448HSTT-X21 Bulb Assembly
Xycom recommends replacing both bulbs at the same time.
Note
