CHS - Ceiling Hinge & Swivel

RS232

- Use an RJ25 connector in the socket marked
RS232 on the control box to operate using RS232
Details
Baud rate: 9600
Stop bit: 1
Parity: None
Databits: 8
IMPORTANT
Ensure protocol is entered exactly as written,
including Carriage Return (Enter / ASCII 13).
PROTOCOL
fa_in Carriage Return (Enter
fa_out Carriage Return (Enter
fa_right Carriage Return (Enter
fa_left Carriage Return (Enter
fa_home Carriage Return (Enter
fa_preset Carriage Return (Enter
fa_a Carriage Return (Enter
fa_b Carriage Return (Enter
fa_c Carriage Return (Enter
Pin 1: RX
Pin 6 : TX
Pin 3 & 4: GROUND
Page 15 of 18 // email info@futureautomation.co.uk tel: +44 (0) 1438 833577 fax: +44 (0) 1438 833565
RJ25
PIN 1: RX
PIN 6: TX
PIN 3: GROUND
PIN 4: GROUND
)
)
) Device OUT RIGHT limit
)
) Device OUT CENTERED
) Device OUT to PRESET memory position
) Device OUT to memory position a
) Device OUT to memory position b
) Device OUT to memory position c
Pin 5: GROUND
TO
TO
TO PIN 5: GROUND
TO PIN 5: GROUND
ACTION
Device IN
Device OUT
Device OUT LEFT limit
Pin 2: TX
Pin 3: RX
9 PIN D
PIN 2: TX
PIN 3: RX
