CHS - Ceiling Hinge & Swivel
Replacing batteries
Operation Buttons - Swivel Mechanism
In - Takes the screen into
the closed/in position
Preset - Screen goes
into learnt position
Store - Programs current
screen location to learnt
positions - see below
< - Rotates screen left
Note
Press STOP between
button presses
Extra Combination:
Move to desired swivel position press STOP and then:
Learn Preset Position = Store - Within 1 sec - Preset
Learn Maximum Right Position = Store - Within 1 sec - F
Learn Maximum Left Position = Store - Within 1 sec - D
Learn Left & right to 180 degrees = Store - Within 1 sec - E
Page 16 of 18 // email info@futureautomation.co.uk tel: +44 (0) 1438 833577 fax: +44 (0) 1438 833565
Future Automation IR Remote
Controller needs x2 AAA batteries
which are provided within the
packaging
Stop - Will stop the
operation at any point
Out - Lowers the screen
into open/out position
Home - Takes screen to forward
facing position from an angled
position
> - Rotates screen right
Telescope Mechanism Control Operation:
Move to desired telescope position press STOP and then:
Store Current Telescope Position = Store - Within 1 sec - C
Clear Stored Telescope Postion: Store - Within 1 sec - B
Note
Only buttons indicated
are functional with the
mechanism
