- Page 1 CM E M O T O RIS ED S WI VEL TV C E IL IN G M OUN T 3 2” - 6 5 ” I N S TA L LA T I O N I N ST R U CTI ON S I SSUE 002...
-
Page 3: Sa Fety Di Sc La Imer
Clean only with a dry cloth and always unplug any electrical items being used in conjunction with this product before cleaning. Future Sound & Vision trading as Future Automation intend to make this and all documentation as accurate as possible. However, Future Automation makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product. - Page 4 Under the warranty, Future Automation aims to either solve the issue remotely (via telephone or email support) or if the mechanism requires a part, arrange a visit to your premises by a Future Automation approved engineer or send replacement items where appropriate.
-
Page 5: Gui D E C O Nt E Nts
GUI D E C O NT E NTS SAFE TY DISCLA IM ER PR OD UCT WA RR A NT Y & RISK ASSESS M EN T GUIDE C ONT ENTS PACKA GE CONTENT S MECH ANISM QUICK-ST A RT GUI D E MO UNTING OPT IONS MO UNTING OPT IONS CONT. -
Page 6: Package Contents
PACKAG E CONT ENTS 1 - ELECTRIC CEILING MOUNT 1.1 - KH SCREEN MOUNT 1.2 - CM POLE 1.3 - CM MOUNT ASSEMBLY 1.4 - CM FLANGE COVER 1.5 - PLASTIC TILT HANDLES 1.6 - SU4 SWIVEL UNIT 1.7 - SIDE MOUNT BRACKETS 1.8 - TELESCOPIC JOIST MOUNTING BRACKETS 2 - IR REMOTE 3 - CONTROL BOX... - Page 7 MEC HA NI SM QUI CK - S TART GUI DE Some Future Automation mechanisms may ship with the control box disconnected to prevent damage during transit. In order to operate the mechanism, the control box will need to reconnected, then have mains power applied along with the desired control method.
-
Page 8: Mounting Options
MO UN TI N G OPT I ON S SURFACE MOUNTING Ensure the mounting surface is structurally suitable and appropriate fixings are used before continuing installation. • Fix to the surface directly through the M6 holes of Base Panel. Base Panel UNISTRUT MOUNTING •... - Page 9 MOUNT ING OPT ION S CONT . MOUNTING BETWEEN JOISTS • Telescopic Joist Mounting Brackets can be secured to the slots in the top faces of the Side Mount brackets. • The Telescopic Joist Mounting Brackets can then be extended to be secured to the joists.
-
Page 10: In S T Alli Ng T Hec Ei L Ing Moun T
Mounting Direction • An M6 Grub Screw is provided as a Locking Screw to lock the manual rotation of the CME. • Press home on the IR Remote, manually rotate until the mounting direction is central, securely fasten the Locking Screw. - Page 11 IN S T ALLI NG T HE C EI L ING MOUN T C O NT. • Screen Mount height can be adjusted by using the higher or lower fixing holes in the middle of the KH Mount Plate. • Alternatively all four mount boss positions can be altered vertically.
- Page 12 - Control Signal (RS232, To mains power IR, Contact Closure) • The CME’s mounting allows for cables from the screen to be fed through the intergrated cable management. This allows the cables to be stowed tidily and safely within the mechanism.
- Page 13 REPLACING MECHANISM BATTERIES The standard Future Automation Infrared (IR) remote control required x2 AAA batteries to operate. These are provided with the mechanism in the Accessories Pack. These batteries can be replaced as the per the image below.
- Page 14 INFRA RED ( IR) This Mechanism can be controlled via the supplied 14 button Infrared (IR) Remote Control, pair with the supplied Infrared (IR) lead and sensor. The mechanism's functions can be controlled by plugging the Infrared (IR) lead and sensor into the 3.5mm IR Input Jack shown on the General Mechanism Control page.
-
Page 15: Radio Frequency
RA D I O F RE QUEN CY (RF) If purchased with the Radio Frequency (RF) control option, this mechanism can be controlled via the supplied 4 button Radio Frequency (RF) Remote Control, paired with the in-built Radio Frequency (RF) sensor. Confirmation of Radio Frequency (RF) input will be shown by a single flash of the large green LED located on the end of the control box. -
Page 16: C Ont Actc Losure
C ONT ACT C LOSURE This Mechanism can be controlled via Contact Closure, utilising an 8 Pin RJ45 Connector attached to a length of CAT5 (Type 568A or 568B) cable. The mechanism's functions can be controlled by plugging this into the RJ45 port on the mechanism control board, then shorting pins 1-8 on this connector as shown in the Contact Closure Input Table below. - Page 17 RS2 32 CON T RO L This Mechanism can be controlled via RS232, utilising a 6 Pin RJ11/RJ25 connector OR 9 Pin Serial connector attached to a length of 6 core cable. The mechanism's functions can be controlled by plugging this into the RJ11/RJ25 port on the mechanism control box, then inputting the RS232 commands shown in the RS232 Input Table below.
- Page 18 NO T E S :...
- Page 20 EUROPEAN OFFICE NORTH AMERICAN OFFICE Address: Address: Unit 6-8 Enterprise Park Brunel Road 127 Venture Drive Bedford Dover Bedfordshire MK41 9TG 03820 Phone: +44 (0) 1438 833577 Phone: +1 (603) 742 9181 Email: info@futureautomation.co.uk Email: info@futureautomation.net Office Hours: Office Hours: Mon - Fri 8:00 to 17:30 GMT Mon - Fri 7:00 to 17:00 EST Saturday &...
