CHS - Ceiling Hinge & Swivel
Package Contents
1 - Mechanism
1.1 - Box
1.2 - Top Trim
1.3 - Left Trim
1.4 - Right Trim
1.5 - Main Tray
1.6 - Cross Bars
1.7 - Screen Uprights
1.8 - Pivot Tube
1.9 - Mount Plates
1.10 - Back Tary
2 - Control Box
3 - IR Remote Control
Not Shown On Page
4 - x2 AAA Batteries
5 - Mains Power & Other Leads
6 - Transformer for Control box
1
1.9
Nuts & Bolts Multipack:
Various Fixing's
1.1
1.3
1.2
CHS with telescopic
add on - CHST
