Installing The Remote Display (Optional); Figure 28. Remote Display Connections (Rear Cover Removed) - Veeder-Root EMR3 Installation Manual

EMR3 Truck Installation

Installing the Remote Display (Optional)

The Remote Display consists of the items listed in Table 12:
Figure 28 shows the Remote Display assembly and Figure 30 shows how to wire the display to the
Interconnection Box. You can mount the display on a wall or dashboard of a truck, a wall in a building, or outside in
a hazardous location. Use appropriate fasteners in any of the pre-drilled holes in the base of the optional bracket
when attaching the bracket to the mounting surface. Adjust the angle of the display by loosening the side bolts
and rotating the unit to the desired position.
Following wiring routing precautions and procedures discussed earlier for the meter mounted Display Head,
connect the Remote Display to the Interconnection Box. Wiring connections at the Remote Display are shown in
Figure 30. Install optional cord grip fitting in rear of Remote Display for cable egress. Wiring connections at the IB
are to the identical terminals of the unused Display Head terminal block.
An optional C&C sealable switch kit (P/N 330020-507) is available containing a front cover accessible push
button C&C mode switch. The switch replaces an internal jumper (between terminals 16 GND and 17 CSS) and
is installed on the front panel of the Remote Display. The installer will have to drill a hole in the front cover of the
display for this switch assembly, then install the switch as shown in Figure 29. A template for locating the C&C
mode switch hole is provided in Appendix B of this manual. These bolt heads have been drilled through for sealing
wire.
Table 12.- Remote Display Components
