SMITH FLOW METER INSTALLATION

Table 4 lists the parts included in the EMR
see Figure 10 on page 15, Figure 11 and Figure 12 on page 16, and Figure 13 on page 17 for instructions on
how to disassemble then reassemble the calibrator.
3
approved adaptor kit. In addition to "Installation Procedure" on page 6,
Table 4.- Display Head-to-Smith Meter Adaptor Kit 846000-005
Item
Wire - Sealing 24" (610 mm) LG
Coupling - Slot 0.130 W
Screw - 0.250-28 x 0.62 Hex
Lockwasher - 0.256 x 0.02
Groove Pin - 0.078 D x 0.562
Groove Pin - 0.063 D x 0.781
Group - Short Shaft
Group - Long Shaft
Installation Procedures - Fuel Oil Truck Application
Qty
V-R P/N
1
011853-285
1
065004-005
4
503615-001
4
510003-006
1
510114-001
1
510105-177
1
331433-001
1
331433-002
14
