EMR3 Truck Installation
A power/data cable and three 2" x 3" (50 x 75 mm) Velcro strips are included in the printer kit. Figure 27 shows
the front panel lights and controls, and the rear panel connections to the TM-295 Slip printer and illustrates the
TM-295 printer's address code setup for DIP switch 3 (which must be set as shown or it will not work) and
suggested positions for the Velcro strips. Remove the rubber feet from the base of the printer to permit maximum
contact between the Velcro strips and the mounting plate.
Attach the four wires of the printer power/data cable to the appropriate terminals of the Power Side terminal block
in the IB (Figure 22 on page 30) and the DB-25 connector and the round power connector to the appropriate
connectors on the rear of the printer.
Scrape off the
4 rubber pads
from the printer's
base
Attach the 3 velcro
strips to the bottom
plate of the printer
Set Pole 3 of
DIP switch ON
emr\print.eps
The printer ribbon should be removed if using "carbonless forms". Power to the printer is re-
quired to release the carriage and install/remove a printer ribbon.
Table 11.- Low-Cab Installation*
Item
Base plate
Pillar stack
Removable platform
*Use Loctite® 243 Threadlocker® on all printer stand mounting bolts.
trademarks of Loctite Corporation.)
Cable from the IB unit
(V-R # 331791-001)
Connect DB-25
data connector
to RS-232 port
RS-232
Connector
clearance
Figure 27. TM-295 printer
SMC P/N
ZPLT-1
PS12-A
VMI-L0
Connect round
power connector
to power port
Rear
Connector
Panel
FG D.K.D. POWER
2.5"
(63.5 mm)
Power On/Off
Switch
36
Installing the Printer (Optional)
(Loctite and 243 Threadlocker are registered
Front Panel Lights
and Controls
POWER
RELEASE
PAPEROUT
FORWARD
REVERSE
RELEASE
Print guide
Slide ticket in face up keeping right side of
ticket against print guide. Push in ticket
as far as it will go. Press the FORWARD key
until the PAPER OUT light turns off.
