3.2. Technical Specifications - VERT-X Operator
Input voltage
1
Motor voltage
Motor power supply
Battery charger
Current consumption (Mains)
Current consumption (motor at rated load)
Current consumption (motor at max load)
Operator push force - maximum
Operator stroke - maximum
Operator speed (at rated load)
Typical gate opening time (90º)
Manual override
Maximum number of operations per day
Design life
Duty cycle (Mains present)
Operations in Standby over 24 hours
(with fully charged 7Ah battery)
Collision sensing
Operating temperature range
Mass of operator packed (excluding battery)
Single kit
8
Double kit
9
1. Can operate off a solar supply, consult your reseller for assistance
2. Can increase battery capacity for longer standby times
3. Assumes that full stroke of operator is used
4. Each operator comes with a unique set of keys
5. Based on 25°C ambient temperature and unit not in direct sunlight
6. Based on an operator push force of less than 50% of rated
7. Based on double kit excluding Infrared Safety Beams
8. Single kit contains one operator and Wall Box
9. Double kit contains two operators and one Wall Box
Battery-driven (standard capacity - 7Ah)
3
5 6
7
page 12
Light-Industrial
90V - 240V AC ± 10%, 50/60Hz
12V DC
CP84SM - 1.8A @ 13.8V
170mA
3A
13A
220kgf
320mm
28mm/sec
<11 sec
Key release
250
150,000 cycles
60%
300
Electronic
-15°C to +50ºC
10kg
18kg
2
4
TABLE 1
