CENTURION SYSTEMS VERT-X Mechanical Installation Manual page 43

10.3.2. Step 2: Wall Bracket Height
Determine a suitable height for the
Wall Bracket.
Be aware that the Wall Bracket is
mounted 35mm higher than the Gate
Bracket. If the gate has limited cross
bars to which the Gate Bracket can
be attached then this will determine
the height of the Wall Bracket.
In most outward opening installations, a custom bracket will have to be made
up by the installer. The VERT-X Wall Bracket is then attached to this custom
bracket.
10.3.3. Step 3: Mounting the Wall
Bracket
10.3.3.1. Determine the Wall
Bracket Position
Find the corresponding A-Value
and B-Value for the installation
determined in Section 10.3.
Using a steel ruler (tape measure) or
the VERT-X ABS template (which can
be purchased as an optional extra),
determine the Wall Bracket length.
For the steel ruler option, this is
achieved by placing the steel ruler
with the 0mm marking at the gate
hinge point and measuring out the
B-Value. The Wall bracket length
is then the difference between the
B-Value and the distance to the pillar
face. This is shown in Figure 40.
For the VERT-X ABS template
option, place the correct B-Value
measurement at the gate hinge
point. The Wall Bracket length
is determined by measuring the
distance from the horizontal line on
the template to the pillar face. This is
shown in Figure 41
www.CentSys.com
Wall Bracket
FIGURE 39. WALL BRACKET HEIGHT
Gate hinge
Wall Bracket
position
A-Value
FIGURE 40. DETERMINE WALL BRACKET
FIGURE 41. DETERMINE WALL BRACKET LENGTH
(USING THE ABS TEMPLATE)
page 43
35mm height
difference
between the Gate
Bracket and the
Wall Bracket
B-Value
LENGTH (USING A RULER)
Gate hinge
Wall Bracket
A-Value
B-Value
position
