100º Inward Opening Gate
E-Value
>77.5mm
>82.5mm
1. Optimum Installation
With this type of operator, it is critical to choose the correct installation
position from the installation tables to ensure that the tip of the
operator does not interfere with the gate during operation.
www.CentSys.com
A-Value
B-Value
150mm
140mm
1
160mm
135mm
C-Value
633mm
1
626mm
page 29
D-Value
110mm
1
1
110mm
TABLE 7
