Remove the operator and then fix the Gate Bracket onto the gate using the preferred
mounting method
C-Value
Gate Hinge Point
FIGURE 30. ATTACH THE GATE BRACKET ONTO A STEEL GATE
9.3.5.2. Using the Metal Template (Optional Extra)
Using the Metal Template available and the Gate Bracket Pin:
Wall
Bracket
Pin
Spirit Level
Gate
Bracket
Metal Template
Pin
FIGURE 31. MOUNT THE GATE BRACKET
