9.3.2. Step 2: Wall Bracket Height
Determine a suitable height for the
Wall Bracket.
Be aware that the Wall Bracket is
mounted 35mm higher than the Gate
Bracket. If the gate has limited cross-
bars to which the Gate Bracket can
be attached, then this will determine
the height of the Wall Bracket.
9.3.3. Step 3: Mounting the Wall
Bracket
9.3.3.1. Determine the Wall
Bracket Length
From Figure 18 and Table 6 find
the corresponding B-Value for the
installation determined in
Section 9.3.1.
Using a steel ruler (tape measure) or
the VERT-X ABS template (which can
be purchased as an optional extra,
determine the Wall Bracket length.
For the steel ruler option, this is
achieved by placing the steel ruler
with the 0mm marking at the gate
hinge point and measuring out the
B-Value. The Wall bracket length
is then the difference between the
B-Value and the distance to the pillar
face. This is shown in Figure 21.
For the VERT-X ABS template
option, place the correct B-Value
measurement at the gate hinge
point. The Wall Bracket length
is determined by measuring the
distance from the horizontal line on
the template to the pillar face. This is
shown in Figure 22.
www.CentSys.com
35mm height
difference
between the
Gate Bracket and
the Wall Bracket
Gate
FIGURE 20. WALL BRACKET HEIGHT
