Mount the template to the Wall Bracket using the bracket pin
•
Rest the spirit level on the template and level the template
•
Holding the Gate Bracket underneath the template (as shown in Figure 31), insert the pin
through the slot in the template and into the Gate Bracket
•
With the gate in the closed position, move the Gate Bracket to the end of the slot of the
metal template
•
Spot weld the Gate Bracket in place OR make the necessary markings if a Bracket has
been made up to fit a non-steel gate
•
To avoid damage, it is recommended that the Metal Template be removed before the
Gate Bracket
•
Fix the Gate Bracket onto the gate using the preferred mounting method as discussed in
Section 6.6
It is advisable to first check that the installation works before permanently fixing
the brackets in place. See section 9.7.
page 36
