3.3. V-Series Controller

Maximum motor current per channel
Maximum input voltage
Standby current draw
Maximum solenoid current draw
Maximum auxillary output current
Collision detection
Position and trajectory
Temperature range

3.4. Lightning Protection

The V-Series electronic controller utilises the same proven surge protection philosophy
that is used in all our products. While this does not guarantee that the unit will not
be damaged in the event of a lightning strike or power surge, it greatly reduces the
likelihood of such damage occurring. The earth return for the surge protection is provided
via the mains power supply earth. In order to ensure that the surge protection is
effective, it is essential that the unit is properly earthed.
3.5. Maximum Allowable Gate Mass and coverage
Length (m)
Mass (kg)
An electronic lock can be fitted to improve the security of the system
www.CentSys.com
Maximum Allowable gate Mass
Up to Up to
1.5m
600kg 335kg
15A (fused)
18V DC
2A DC
3A (Resettable Electronic Fuse)
Current sense and redundant optical
Redundant optical
-20°C to +60°C
Up to
2m 2.5m
215kg
page 13
48mA
Up to
3m
150kg
TABLE 2
TABLE 3
