4. Product Identification
1
2
3
4
5
6
7
1. Gate operator keys
2. Wall Bracket mounting plate
3. Wall Bracket
4. VERT-X gate operator
(complete assembly)
5. Wall Bracket pin
1.
Keys are specific to each operator - key number must be recorded
www.CentSys.com
1
FIGURE 2. PRODUCT IDENTIFICATION
6. 14mm snap rings
7. Mechanical Installation Manual
8. Gate Bracket welded assembly
9. Gate Bracket pin (optional extra)
10. Gate warning decal
page 15
8
9
6
10
